12 Speakerphone
key
Enables you to place and receive calls using the speakerphone. The key glows
green when activated.
13 Headset key Enables you to place and receive calls through a headset. The key glows
green when an analog headset is activated, and blue when a USB or Bluetooth
headset is activated.
14 Navigation key/
Select key
Scrolls through information or options displayed on the phone's screen. Selects
a field of displayed data.
15 Home key Displays the Home screen from other screens, and displays the Lines and
Calls screens from the Home screen.
16 Line keys Enable you to select a phone line, view calls on a line, or quickly call a favorite
contact.
17 Screen Shows a 3.5-inch (8.89 cm) diagonal screen with a backlight that enables you
to view menus and data.
18 Message
Waiting
Indicator
Flashes red to indicate when you have new messages.
19 USB Port Enables you to attach a USB flash drive or USB headset (VVX 411 only).
VVX 500 Series and VVX 600 Series Hardware
The following figure displays the hardware features on the VVX 500, 501, 600, and 601 business media
phones. The table lists each feature numbered in the figure.
VVX 500 series and VVX 600 series hardware features
Getting Started with a VVX Business Media Phone
Polycom, Inc. 16
