Icons and Status Indicators on VVX 500 Series and 600 Series Business Media Phones
The following table displays the phone icons and status indicators that display on VVX 500 series and
VVX 600 series business media phones.
Icon Description Icon Description
Registered line Status indicators in Lines screen. A
flashing red bar indicates held calls.
A green bar indicates an active call.
Unregistered line Do Not Disturb enabled
Outgoing Call Phone warning
Active call using Polycom HD Voice Login credentials invalid
Held call Shared line
Incoming call Call forwarding enabled
Active conference Recent calls
USB flash drive attached USB flash drive in use
Placed call Presence status (Available)
Received call Presence status (Busy)
Missed call Presence status (Away)
Bluetooth available
(VVX 600/601 only)
Presence status (Do Not Disturb)
Bluetooth disconnected
(VVX 600/601 only)
Presence status (Offline)
New message Presence status (Unknown)
Related Links
Features for Hearing-Impaired Users on page 165
Getting Started with VVX Business Media Phones
Polycom, Inc. 26

Polycom VVX 201 Series Specifications

General

SIP Accounts	2
Headset Support	Yes
Lines	2
SIP Protocol Support	Yes
Headset Port	RJ-9
Wireless	No
Bluetooth	No
USB Port	No
Power over Ethernet (PoE)	Yes
Audio Features	Acoustic Clarity Technology
Network Protocols	SIP, SDP, RTP, RTCP
Power	PoE or optional external AC adapter
Codecs	G.711, G.722, G.729
Supported Codecs	G.711, G.729AB, G.722
Conference Capabilities	Yes
Supported Protocols	SIP, SDP, RTP, RTCP
Ethernet Ports	2 x 10/100 Ethernet Ports
