5.7 WAVS Synth Voice
WAVS is a 2 oscillator wavetable synthesizer. The wave stage
output acting as the oscillator section. Wave le positions are
scanned and the wave is stretched and morphed. The application of a lter
stage also affects the audio output. Modulation of the warp and position can
produce an interesting output.
WAV
File 1
WAV
File 2
Filter
15 Classic
Models
Volume
Amp
LFO 2LFO 1
Preset
Glide
Tune
Tune
Position
Position
Warp
Warp
WAVS
Engine Oscillator - Page 1
WAV File WAV File Retro Mode
Source Sample File Source Sample File On - Off
Wavetable 1 sample
selected from the Samples/
WAVS folder on SD Card.
Both wavetables are blended
together and ltered.
Wavetable 2 sample
selected from the Samples/
WAVS folder on SD Card.
Both wavetables are blended
together and ltered.
Changes character of synth
Position 1 Position 2 Mix
0-100 0-100 -100 to +100
Position in the wavetable Position in the wavetable Blended mix of wavetables
Warp 1 Warp 2 Noise
-100 to +100% -100 to +100% 0-100%
Manipulates the phase to
stretch and warp the audio
wav.
Manipulates the phase to
stretch and warp the audio
wav.
Amount of noise applied
Filter - Page 1
Cutoff Resonance Type
Frequency: 20Hz - 20kHz Amount: 0-100% Filter Model
Frequency point at which the
audio is attenuated.
Emphasises the frequencies
at the cutoff position.
Low Pass MG 24dB, Low
Pass OB 24dB, Low Pass OB
12dB, Low Pass SVF 24dB,
Low Pass SVF 12dB, Hi Pass
OB 24dB, Hi Pass OB 12dB,
Hi Pass SVF 24dB, Hi Pass
SVF 12dB, Band Pass OB
24dB, Band Pass OB 12dB,
Band Pass SVF 24dB, Band
Pass SVF 12dB, Notch SVF
24dB, Notch SVF 12dB,
Envelope Amount Note Track
Amount: -100% to +100% Amount: -200% to +200%
Amount of envelope applied
to the lter.
Amount of modulation
applied based on the pitch of
the note played.
Engine Oscillator - Page 2
Tune 1 Tune 2 Detune
-36 to + 36 st -36 to + 36 st 0-100 Cents
Oscillator 1 Tuning in
semitones
Oscillator 2 Tuning in
semitones
Oscillator mix detuning in
cents
Finetune
-100 to +100 Cents
Fine tuning of the mix in
cents
Engine Oscillator - Page 3
Glide Mode Glide Time Volume
Options 0.00 -3 Secs 0-200%
Slide between notes:
Always, Overlap, Legato i.e.
Envelopes are not triggered,
Legato Overlap
Time of slide between notes. Volume level of oscillator
voice
Noise
Mix
Detune
Retro
Mode
Finetune
Aux
ADSRADSRADSR
