Precor Experience Series User Manual

Specifications
System Component Specification
Single Stage Belt Drive Tension 93-100 lbs (42- 45 kgs)
Procedures
Review entire procedure before starting.
Removal Instructions
1. Remove the left and right Drive Housing Covers, see "Drive Housing Covers Replace-
ment" on page88.
2.
Use a 1/2" socket to loosen the idler pulley bolt .
3.
Loosen the 1/2" belt tension adjustment bolt to relax the belt tension.
4. Then walk the drive belt off the input module pulley and remove.
Installation Instructions
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 104
6 Replacement Procedures
Drive Belt Replacement
