Precor Experience Series User Manual

1.
Route the drive belt around the idler pulley and generator pulley . Then walk
the drive belt onto the input module pulley .
2. Spin the Crank a couple of rotations to move and seat the drive belt. Make sure that the
belt is centered and that the belt grooves are properly seated onto input module pulley
and generator pulley .
3. Adjust the drive belt tension to specification, see "Single Stage Drive Belt Tension
Adjustment" on page47.
4.
Make sure the idler pulley bolt is fully tightened.
5. Reinstall the Drive Housing Covers, see "Drive Housing Covers Replacement" on
page88.
6. Verify operation and return to service, see Operation Verification.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 105
6 Replacement Procedures
Drive Belt Replacement
