Ramp Assembly Replacement
About
This procedure provides instructions to remove and install the Ramp assembly.
Specifications
System Component Specification
Ramp-Pivot Mounting Bolts (Nylock) 1080 in-lbs (90 ft-lbs or 122 Nm)
Ramp-Yoke Mounting Bolts 330 in-lbs (27.5 ft-lbs or 37.2 Nm)
Ramp Pivot Hinge Mounting Bolts 96 in-lbs (8 ft-lbs or 10.8 Nm)
Forward Ramp Cover fasteners 30 +/- 9 in-lbs (3.4 +/- 1 Nm)
Procedure
Review entire procedure before starting.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 187
6 Replacement Procedures
Ramp Assembly Replacement
