5.
Fully tighten the idler pulley bolt . Then manually rotate the Input Drive pulley to seat
the belt. If the belt tension is not within specification, repeat the belt tension adjustment
steps.
6. Reinstall the Drive Housing Covers and any other removed covers, see "Drive Housing
Covers Replacement" on page88.
7. Verify operation and return to service, see "Operation Verification" on page16.
See Also
"Second Stage Drive Belt Tension Adjustment" on page56
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 50
5 Adjustment/Calibration Procedures
Single Stage Drive Belt Tension Adjustment
