Procon V3D - Terminal Push Button Functions and Programming

H - I - J PROGRAMMER’S MANUAL V8.94.11-
- 12 -
Functions of the push buttons (operating and controlling terminal)

(Escape)
▪ Change between display mode and programming mode
▪ Parameter setting mode: shift the cursor to the left
▪ Repeated push: exit parameter setting mode without saving (until the cursor blinks)
▪ At error display: displaying the cause of the error

▪ Display mode: scrolling the displayed variables downward
▪ Programming mode: moving in the menu downward
▪ Parameter setting: decreasing the value or scrolling the selector switches downward
▪ With selected terminal motor potentiometer: decreasing the reference signal
▪ With enabled motor potentiometer start / stop: Stop

▪ Display mode: scrolling the displayed variables upward
▪ Programming mode: moving in the menu upward
▪ Parameter setting: increasing the value or scrolling the selector switches upward
▪ With selected terminal motor potentiometer: increasing the reference signal
▪ With enabled motor potentiometer start / stop: Start

(Enter)
▪ Programming mode: starting the parameter setting
▪ Parameter setting mode: shift the cursor to the right
▪ Repeated push: save parameter value (until the cursor blinks)
▪ Acknowledgement at error
Programming procedure (operating and controlling terminal)

(Escape)
▪ Changing from display mode to programming mode

▪ Moving between the menu items

(Enter)
▪ Starting parameter setting



▪ Parameter setting

(Enter)
▪ Repeated push: save parameter value (until the cursor blinks)
or

(Escape)
▪ Repeated push: exit parameter setting mode without saving (until the cursor blinks)
