Time periods
With the use of the time intervals operation according to the calendar can be set. There is possibility for setting every
day, every weekday or operation intervals repeated in each week!
„Time interval1,2,3” is active, if any time interval is in switched-on state.
i
Take care of the correct setting of the calendar in menu 11 System!
Submenu
Explanation, further submenus
Values
Default setting
Unit
5-26
period 1.
Here the times of the switch-on and switch-off of the first time interval can be set.
5-26-1 on
5-26-1-1 day
no
every day
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
weekdays
no
5-26-1-2 hour
0 - 23
0
5-26-1-3 minute
0 - 59
0
5-26-1-4 second
0 - 59
0
5-26-2 off
5-26-2-1 day
no
every day
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
weekdays
no
5-26-2-2 hour
0 - 23
0
5-26-2-3 minute
0 - 59
0
5-26-2-4 second
0 - 59
0
5-27
period 2.
The setting is the same as that of item 5-26 time interval 1.
5-28
period 3.
5-29
PID extension
The PID extension makes it possible to supplement 1 regulated unit even with further 3 fix
switchable units (e.g. pressure control for more than one pump).
5-29-1 turn on delay
The time elapsing after reaching fmax until the
switch-on of the next unit.
0,0 - 5000,0
10,0
s
5-29-2 turn off delay
The time elapsing after reaching fmin until the
switch-off of the next unit.
0,0 - 5000,0
10,0
s
5-29-3 hysteresis
The switch-on and switch-off delay starts in this
distance from fmax and fmin.
0,0 - 100,0
1,0
Hz
