Procon V3D - IRE Transmitter Configuration

H - I - J PROGRAMMER’S MANUAL V8.94.11-
- 41 -
Incremental rotation speed signal transmitter (IRE) parameters
Incremental rotation speed signal transmitter inputs
At digital inputs, selecting „N” means inactive input, except for IRE inputs!
If both (A and B) IRE inputs are selected to “N”, then they can be used as incremental rotation speed signal transmitter
inputs (A or B).
In case of 2-phase IRE, if any IRE input (A or B) is used as function input, even the other cannot be used as IRE input!
In case of 1-phase IRE, the IRE B input can be used as digital input.
At V3D types, for IRE inputs input 5 and input 6 can only be used, at types VLD and VHD primary inputs 7 and 8, for a
second IRS input inputs 5 and 6 can be used at proper configuration.
If no IRE input is needed, they can be used for digital input, as all other inputs.
Submenu
Explanation, further submenus
Values
Default setting
Unit
4-31
IRE data
Parameters necessary for rotation speed and position regulations.
4-31-1 resolution
Its setting means the number of pulses during one
revolution of the IRE.
0 - 10000
1000
imp/rot.
4-31-2 rotation speed 100%
At rotation speed regulations.
0 - 6000
1500
f/min
4-31-3 position 100%
At position regulations.
0 - 50000
1000
rot.
4-31-4 position=0
Setting the basic position of the incremental signal
transmitter given in menu 4-31-5.
now
by start
to prg. cycle start
now
4-31-5 position 0 value
Percent of the reference signal the basic position
is to understand at.
0,00 - 100,00
0,00
%
4-31-6 type
2 phases: Signal transmitter connected to IRS A
and B inputs
1 phase: Uses the IRS A input only. To this input,
the pulses arrive if the motor runs. With
1-phase signal transmitter, sensing of
the rotation direction is not possible, thus
in this case the direction will always be
the designated direction of the frequency
converter.
2 phases
1 phase
2 phases
4-31-7 filter
no
yes
no
The parameters of the primary IRE can be set in menu 4-31.
The primary IRE can be used as feedback signal for:
• rotation speed control,
• torque control,
• position control,
• field oriented control with signal transmitter
as well as in case of demand for reference signal source, for
• regulation and
• control
The secondary IRE (IRE 2) which can be established in VLD and VHD types, can only be used as reference signal
source.
The parameters of the primary IRE apply also to the secondary IRE.
If the reference signal source is an IRE, the frequency converter has to be set by the slave.
