Exceptions at loading the parameters set
Depending on the source of loading or on the parameter set to be loaded, the parameters and settings below will be
loaded in the following cases only (X):
Parameters, settings
From the
frequency
converter
memory
From terminal memory
At matching
type
At not matching
type
3-8-1 maximum DC brake current
X
X
-
3-8-4 DC brake de-excitation time
X
X
-
3-9-2 resistor brake value
X
X
-
3-9-3 resistor brake value maximum load
X
X
-
3-9-4 resistor brake voltage
X
X
-
4-9-3 DC brake current
X
X
-
6 Motor menu (full menu item)
X
X
-
7-2-1 U boost
X
X
-
11-6-1 modulation carrier frequency
X
X
-
11-6-3 modulation changing frequency
X
X
-
11-18 manufacturing number (full menu item)
-
-
-
11-19 version (full menu item)
-
-
-
11-20 date (full menu item)
-
-
-
11-21 currents (full menu item)
X
-
-
11-22 voltages (full menu item)
X
-
-
11-23 special data (full menu item)
X
-
-
11-27 menus with password (full menu item)
-
-
-
User password
-
-
-
Installer password
-
-
-
Modifying parameters based on saved parameter set
There is possibility for uploading not only complete parameter sets, but also for modifying certain parameters only, based
on the saved parameter set. Whether to load the complete parameter set or only a part of it can be set in menu 11-1-1-
4 group. Here macros are listed, and the parameters included in the given macro can be appointed for being uploaded.
At loading a parameter set of 11-1-1-1 memory or 11-1-1-2 terminal, only the parameters appointed in the 11-1-1-
4 group menu item will be loaded.
There is also possibility for loading parameters belonging under a given menu (submenu) only. E.g. if the same control
is used in more equipment then it is enough to set it once, save the parameter set in the terminal, and load in the other
equipment only the parameters belonging under menu 1 (or 1-6).
For this, the menu item is to be selected in the menu 11-1-1-4 group and in menu 11-1-1-3 menu item the menu to
be loaded is to be set: 1-0-0-0 (or 1-6-0-0)
After this, the parameters can be loaded from the terminal in menu 11-1-1-2 terminal as already known.
By selecting in 11-1-1-3 menu item the value 0-0-0-0, the structure of the quick menu can be appointed for loading.
By setting in 11-1-1-3 menu item the value 4-9-2-0, e.g. the parameter ‘4 motorized potentiometers’ can be loaded.
