Productivities
Using the productivity parameters, there is possibility to display any technology value, which is in linear conjunction with
some parameter selectable in the 10-x-1 selection menu.
This proportionality can be established with a compliance value assigned to the nominal value or to 100%.
Four different productivity values can be set.
Submenu
Explanation, further submenus
Values
Default setting
Unit
10-7
productivity 1.
10-7-1 selection
Interpretation of the 100% values:
frequency 100Hz
Imotor In
Umotor Un
Udc 1000V
Unet 1000V
Pinp. Pn
control ref. s. 100Hz
mod. cont. ref. s. 100Hz
reg. ref. s. 100%
mod. reg. ref. s. 100%
feedback 100%
error signal 100%
analogue IN 1,2,3,4 10V / 20mA
analogue IN 1-2,3-4 10V / 20mA
counter 1,2,3 10000
run time 1,2 1000h
heatsink 100C
n n sync.
n ENC n 100% (4-31-2)
torque Mn
Pbrake average 100%
Pbrake current 100%
frequency
Imotor
Umotor
Udc
Unet
Pinp.
control ref. s.
mod. cont. ref. s.
reg. ref. s.
mod. reg. ref. s.
feedback
error signal
an. IN1
an. IN2
an. IN3
an. IN4
an. IN1-2
an. IN3-4
counter 1
counter 2
counter 3
run time 1
run time 2
heatsink
n
n ENC
torque
Pbrake average
Pbrake current
frequency
10-7-4 correspondence
0,1 - 6000,0
1,0
10-7-5 dimension
In menu items 10-11-1 and 10-11-2 further two
dimensions can be defined.
-
percent %
quantity
mass kg
mass t
length mm
length m
speed m/s
speed m/m
speed km/h
volume l
volume m3
rpm
pressure bar
pressure Pa
temperature °C
frequency Hz
user 1
user 2
-
%
pcs
kg
t
mm
m
m/s
m/m
km/h
l
m3
f/p
bar
Pa
°C
Hz
10-7-6 name
xxxxxxxx
prod1
