Dynamic state back indications
These items are displayed in the mid if the status row. Display happens in the moment of occurrence, and it lasts at
least until the minimum perception time (approx. 0.4 sec), or until the dynamic operation state exists.
In case of more than one status to be displayed the frequency converter displays all of them sequentially one after the
other (changing approx. in each 0.8 sec).
The possible dynamic operation states
Displayed text
Explanation
! Error !
Error occurred. On pushing the “Escape” button, it will be jumped to the error menu where the error
can be inspected
U DC<>
The DC voltage in the intermediate circuit is too low or too high for the operation. The equipment
cannot receive start command
Stop
Stop state is forced to the equipment (e.g. from digital input). The equipment cannot receive start
command
DC brake
This signals the operation of the DC brake (3-5 mode of stop mixed or DC brake, or continuous
DC brake command from digital input)
Spin out
Signals the motor stop with spin out (3-5 mode of stop spin out or continuous spin out command
from digital input)
Stop
Appears in case of stop during the run down of the frequency.
f hold
Frequency change inhibited (e.g. from digital input)
Jog
Jog command is active (e.g. from digital input or from programming terminal)
Counter stop
Some of the counters programmed to stop 0 reached the 0 value and released stop.
Mpot.stp
Stop command given with motorized potentiometer.
AnIN.stp
Stop command given with analogue input.
Virt.stp
Virtual input programmed to stop is active (e.g. active comparator)
Waiting
Suspension of the start state (e.g. regulation stop or waiting command from digital input)
R brake
Signals the operation of the resistor brake.
Prog.1-15.
The program with the given number is active.
Tiemint.
Some of the time intervals is active.
U DC lim
The DC voltage in the intermediate circuit is in the lower or upper operation limit.
M.limit
The frequency converter reached the preset torque limit.
I.limit
The frequency converter reached the preset current limit.
Gen.mode
The motor feeds back in the frequency converter (e.g. fast stop)
Mot.pot.
The value of the motorized potentiometer changed.
St.confl.
Conflicting start inputs (start normal and start inverse) are selected.
Contr.stp
Stop command given because of low error signal.
