Procon V3D - Braking Mechanisms and Support Functions

H - I - J PROGRAMMER’S MANUAL V8.94.11-
- 30 -
Submenu
Explanation, further submenus
Values
Default setting
Unit
3-7
free time
In case of stop with spin out, during this time an
other start command remains ineffective, for
disabling a restart.
2-8 start mode: in „normal” mode the running
unit cannot be restarted.
0,1 - 1000,0
4,0
s
3-8
DC brake
The 6-4 motor nominal current (In) parameter overrules the brake current. Even with setting
larger current, the frequency converter permits the nominal current of the motor as a maximum!
The operation of the DC brake is shown in the status display ("DC brake").
i
In case of activating from digital input, also current values differing from this can be
set (4-9-3 continuous DC brake current).
3-8-1 maximum DC brake current
0,0 - type-dep.
type-dependent
A
3-8-2 changing frequency
With mixed stop (3-5 stop mode), above the
switch-over frequency the normal brake, below it
the DC brake will be effective. At higher
frequencies the DC brake is not so effective.
0,1 - 25,0
1,0
Hz
3-8-3 operation time
0,0 - 1000,0
2,0
s
3-8-4 de-excitation time
At pure DC brake
0,10 - 2,00
0,20
s
3-9
resistor brake
Without being equipped with resistor brake, at generator mode (e g. at fast deceleration) the
frequency converter limits the gradient of slope, if it is needed for providing secure stopping!
If the resistor brake is enabled, its operation is shown in the state display („R brake”)!
3-9-1 permission
yesVent: In case of start the frequency converter
turns on also the ventilator. After expiry
of the start state, the ventilator operates
for further 2 minutes. In case of
connecting a brake module with
ventilator, the ventilators of the brake
resistor can work together with the
ventilators of the equipment.
no
yes
yesVent
no
3-9-2 R value
type-dependent
type-dependent
Ω
3-9-3 maximum load
type-dependent
type-dependent
W
3-9-4 U brake
Brake switch-on level
600 - 720
660
V
3-10
Udc hold
At expiry of the supply voltage, the equipment
strives to hold the minimum value of the DC
voltage necessary for the operation! (with
decreasing f)
N
1 - 100
N
%
3-11
brake operation
After the motor stopped, for the time set here,
standing torque will be given to the motor,
permitting time for activating a possible
mechanical brake.
0,00 - 30,00
0,00
s
3-12
Udc filter
The time constant of the filter used at measuring
the DC voltage can be set here.
It serves avoiding the swingings caused by the of
the driven mass!
1 - 200
200
ms
3-13
emergency fall
time
At activating the emergency stop input, the
equipment stops with the fall steepness set here.
0,05 - 3276,7
2,50
s
