H - I - J PROGRAMMER’S MANUAL V8.94.11-
- 40 -
Submenu
Explanation, further submenus
Values
Default setting
Unit
4-30
slave data
4-30-1 frequency ratio (slave multiplier)
In control it can be used for pre-coupling
depending on the frequency of the master.
0,01 - 10,00
1,00
4-30-2 rotation speed ratio
Rotation speed of the slave related to that of the master.
For accurate setting both multiplier and divider can be set!
(e.g. the ratio of 14.5 can be set with multiplier 145 and divider 10.)
This method permits even setting a ratio of e.g. 1/3! (multiplier: 1 and divider: 3)
i
During operation, the rotation speed ratio can only be modified by setting the
multiplier and the divider jointly! For leaving any value unchanged without
modification, it has to be approved with the “Enter” button.
4-30-2-1 multiplier
1 - 32000
1
4-30-2-2 divider
1 - 32000
1
4-30-2-3 dynamic
Enables the marker adjustment
no
yes
no
4-30-3 modification mode
The modification concerns the position or the
rotation
rotation: it modifies the 4-30-2-1 rotation ratio
multiplier.
position: it modifies the 4-31-3 position 100%.
rotation
position
rotation
4-30-4 angle position (slave lag)
4-30-4-1 degree
It can enrol positive values only.
(E.g. at 10 slave “delay” 10, whereas
at 10 slave “hurry” 350.
0,0 - 360,0
0,0

4-30-4-2 rot.
N - 50000
N
4-30-5 marker regulation
4-30-5-1 proportional
0 - 500
100
%
4-30-5-2 integration
0 - 500
100
%
4-30-6 transcript
Here can be set the number of rotations of the driven axle until the motor makes one rotation.
4-30-6-1 multiplier
1 - 32000
1
4-30-6-2 divider
1 - 32000
1
