PROLiNK PRC3801 - 6 Technical Specification

PROLiNK® PRC3801 Wireless AC1200 MU-MIMO Dual-Band Gigabit Router
6 Technical Specification
Specifications
WiFi Standard
• Concurrent Dual-Band; IEEE 802.11b/g/n (2.4GHz); IEEE 802.11a/n/ac
(5GHz)
RF Output Power • 2.4GHz Max 20 dBm; 5GHz Max 20 dBm
Data Rate • 300Mbps (2.4GHz); 867Mbps (5GHz)
Wireless Mode • Router/Access Point (AP)/Repeater Mode
Security
• 64/128-bit WEP, WPA-PSK/WPA2-PSK, MAC Address Filtering; Wi-Fi
Protected Setup (WPS)
Firewall • DoS, IP/MAC Filtering, DMZ
Interface
• WAN x 1: 10/100/1000Mbps Auto MDI/MDIX Ethernet Port (RJ45)
• LAN x 1: 10/100/1000Mbps Auto MDI/MDIX Ethernet Port (RJ45)
• USB2.0 x 1
Buttons • Power, WPS, WLAN, Reset
Antenna • 4 x Fixed High-Gain Antenna
Power Adapter • 12VDC/1A
Power
Consumption
• 10W (Maximum)
Dimension
• 152 x 120 x 27 mm (Product Only)
• 238 x 55 x 230 mm (With box)
Weight
• 255g (Product Only)
• 586g (With box)
Warranty Refer to Service Policy and Warranty
