Technical Data
4Technical Data
4.1 Identcode
Please enter the identcode on the device label into the grey box below.
Fig. 02
FPM = Fluorine Rubber
Series
Type
Material
PP Polypropylene
NP Acrylic/PVC
PV PVDF
TT PTFE with carbon
SS stainless steel
BT4A 1000, 1601, 1602, 1005, 0708, 0413, 0220
BT5A 0000, 0000, 0000, 1605, 1008, 0713, 0420, 0232
Custom version
. . . . . . . . . . . . . . . . .
Custom version
. . . . . . . . . . . . . . . . .
0 no options . . . . . . . . . . . . . . .
_ _ _ _
_ _ ____________
_ _ _ _ _ _
_
Diaphragm and Seal
E standard with EPDM seals
B standard with FPM seals
T standard with PTFE flat seals
Liquid end Version
0 no bleed valve, no valve springs
1 no bleed valve, with valve springs
2 with bleed valve, no valve springs for PP, NP and PV only
3 with bleed valve, with valve springs for PP only
4 no-vent with valve springs for highly viscous media
9 self-degassing for PP and NP
Hydraulic Connections
0 standard connections
Version
0 with ProMinent
®
logo
Electrical Connections
A 200–230 V, ±10 %
B 100–115 V, ±10 %
U 100–230 V, ±10 %
M 12....24 V DC (only BT4a)
N 24 V DC (only BT5a)
P 24 V AC
Cable and Plug
A 2 m European
B2 m Swiss
C2 m Australian
D2 m USA
12 m open end
Relay
0 no relay
1fault indicating relay (N/C)
3fault indicating relay (N/O)
4 as 1 + pacing relay
5 as 3 + pacing relay
Custom version . . . . . . . . . . . . . . . . . . . .
Accessories
0 no accessories
1 with foot and delivery valve, 2 m PVC tubing,
5 m PE tubing
Custom version . . . . . . . . . . . . . . . . . . . .
Custom version
. . . . . . . . . . . . . . . . .
Custom version
. . . . . . . . . . . . . . . . .
Custom version
. . . . . . . . . . . . . . . . .
Custom version
. . . . . . . . . . . . . . . . .
Custom version
. . . . . . . . . . . . . . . . .
Custom version
. . . . . . . . . . . . . . . . .
Control type
0 no lock
1 with lock; manual operation locked when external
cable plugged in
Options on request
Custom version
0 no options . . . . . . . . . . . . . . .
0 no options . . . . . . . . . . . . . . .
0 no options . . . . . . . . . . . . . . .
