ProMinent Beta BT4a - General User Information; Major Components

General User Information:
This operating instructions manual contains the product descriptions in the main text.
• main points
➤ instructions
and safety information are indicated by pictograms (see chap. 2).
NOTE
Working guidelines.
Major Components
Illustrated views of Beta
®
Page 2
Fig. 01
Page 1
3.1
a
d
b
c
3.2
a
d
b
c
3.3
a
d
b
f
3.4
a
d
b
f
3.5
a
e
b
d
1
a
b
c
d
e
f
g
h
2
a
b
1 2 3
g
c
g
c
c
ProMinent
®
Major Components
1 Control unit
1a Stroke length adjustment knob
1b Red LED display, fault indicator
1c Yellow LED display, warning indicator
1d Green LED display, operating status
1e Multifunction switch
1f Mains connector
1g External operating terminal
1h Float switch connector
2 Power end
2a Relay insertion point
2b Optional relay
3 Liquid end
3.1 Liquid end without bleed valve, with/without valve spring
3.2 Liquid end without bleed valve, with/without valve spring
3.3 Liquid end with bleed valve, with/without valve spring (PP-version)
3.4 Liquid end with bleed valve, with/without valve spring (NP-version)
3.5 Self-degassing liquid end
3a Liquid end back plate
3b Liquid end
3c Suction connection
3d Discharge connection
3e Bleed valve connection (self degassing liquid ends)
3f Bleeding/fine bleeding valve
3g Bypass tubing nozzle
