Page 43
Exploded diagrams of liquid ends
Liquid end 0232
without degassing
The listed items are included in the spare parts kit.
* Customer accessories
Subject to technical alterations.
1 Seal set 9.2-2 PVT 1023129
4 Valve balls 9.2 404281
Connector kit 12/9 PVT 1023248
Discharge valve set 9.2-2 PVT 1023125
Diaphragm 0232 1000251
Suction valve set 9.2-2 PVT 1023126
Connector kit
*
*
