ProMinent Beta BT4a - Liquid End 0232 TT

ProMinent
®
Page 46
Exploded diagrams of liquid ends
Liquid end 0232
TT
*
*
60_07-104_00_35-04_2
Connector kit 12/9 TTT 817202
Discharge valve set TTT 809444
Diaphragm 0232 1000251
Suction valve set TTT 809445
Connector kit
4 valve balls 404281
12 seals PTFE 483975
Spare parts kits for:
Type Material Order No.
0232 TTT 1001755
The listed items are included in the spare parts kit.
* Customer accessories
Subject to technical alterations.
