ProMinent
®
Page 14
4.4 Reproducibility
Reproducible
metering accuracy –5 % to +10 % at max. stroke length and max. back pressure for versions in all materials.
Reproducibility ±2 % under constant conditions and at minimum 30 % stroke length.
As the self-bleeding pump is used with outgassing media and in application with gas-bubbles,
the metering accuracy and reproducibility cannot be indicated.
The recommended min. stroke length for selfbleeding dosing pumps is 50 %.
4.5 Viscosity
The metering pumps are intended for use with liquids with a viscosity of up to:
• max. 200 mPas for standard liquid end
• max. 500 mPas for spring valves
• max. 50 mPas for self-degassing metering pumps.
4.6 Materials Information
Technical Data
4.7 Electrical Data
•Version: 200-230 V ±10 %, 50/60 Hz
FPM = Fluorine Rubber
230 V/AC Version Beta
®
/ 4 Beta
®
/ 5
Nominal capacity: 17 W 22 W
Current (l eff) 0.2 A 0.3 A
Peak current: 1.2 A 2.8 A
Peak switching current: 15 A for < 1 ms 15 A for < 1 ms
Fuse: 0.8 AT 0.8 AT
Version Liquid end Valves Seals Valve Balls
PPE Polypropylene Polypropylene EPDM ceramic
PPB Polypropylene Polypropylene FPM ceramic
NPE Acrylic PVC EPDM ceramic
NPB Acrylic PVC FPM ceramic
PVT PVDF PTFE with carbon PTFE ceramic
TTT PTFE with carbon PTFE with carbon PTFE ceramic
SST stainless steel No. 1.4571 stainless steel No. 1.4571 PTFE ceramic
BA_BE_021_07_08_GB2.p65 17.07.2008, 14:35 Uhr14
