ProMinent Beta BT4a - Sizes and Weights

ProMinent
®
Page 9
10/15
41/36
81/96
K
132/144
L
(not 0232)
12
E
95/101
148/160
F
92/102
80/80
M
12 (not 0232)
Beta
®
/ 4 Beta
®
/ 5
1000 – 1602 1005 0708 – 0413 0220 1605 1008 – 0713 0420 0232
E 17 7 9 9 13 15 15 5
F 180 187 185 185 193 191 191 197
K 71 71 74 76 71 74 76 76
L 106 105 108 110 105 108 110 91
M Ø 70 Ø 90 Ø 90 Ø 90 Ø 90 Ø 90 Ø 90 Ø 110
Technical Data
4.2 Sizes and Weights
Materials option: PP
Dimensions Beta
®
/ 4 / Beta
®
/ 5
Materials option: NP
81/96
132/144
41/36
10/15
K
L
M
14
80/80
92/102
E
95/101
148/160
F
Dimensions Beta
®
/ 4 / Beta
®
/ 5
Beta
®
/ 4 Beta
®
/ 5
1000 – 1601 1602 1005 0708 0413 – 0220 1605 1008 0713 – 0420 0232
E 19 17 10 9 9 16 15 15 5
F 171 173 180 181 181 186 187 187 197
K 77 77 74 74 76 74 74 76 76
L 105 105 102 102 104 102 102 104 91
M 62 (Ø 70) 66 (Ø 70) Ø 90 Ø 90 Ø 90 Ø 90 Ø 90 Ø 90 Ø 110
