Technical Data
K
M
44
92/102
80/80
E
95/101
F
132/144
81/96
10/15
41/36
L
148/160
Dimensions Beta
®
/ 4 / Beta
®
/ 5
Materials option: PP and NP SEK
Beta
®
/ 4 Beta
®
/ 5
1601 – 1602 1602 1005 0708 0413 – 0220 1605 1008 0713 – 0420
E 19 17 10 9 9 16 15 15
F 171 173 180 181 181 186 187 187
K 77 77 74 74 76 74 74 76
L 92 92 89 89 91 89 89 91
M 62 (Ø 70) 66 (Ø 70) Ø 90 Ø 90 Ø 90 Ø 90 Ø 90 Ø 90
Materials option: PVDF
92/102
80/80
148/160
95/101
F
E
132/144
81/96
10/15
41/36
M
K
L
1000-1602 1005 0708-0413 0220 1605 0408-0713 0420 0232
E19 8 8 8 14 14 14 4
F 179 185 185 185 191 191 191 198
K71 71 73 75 71737576
L84 88 90 92 88909293
MØ 70 Ø 90 Ø 90 Ø 90 Ø 90 Ø 90 Ø 90 Ø 110
