Liquid end 1000-1005 (1605)
PVT with degassing
The listed items are included in the spare parts kit.
* Customer accessories
Subject to technical alterations.
Connector kit 6/4 PVT 1023246
Connector kit 8/5 PVT 1023247
Discharge valve set 4.7-2 PVT 1023127
Suction valve set 4.7-2 PVT 1023128
Connector kit
Diaphragm 1000 1000244
Membran 1601 1000245
Membran 1602 1000246
Membran 1005 1000247
1 Seal set 4.7-2 PVT 1023130
4 Valve balls 4.7 404201
Exploded diagrams of liquid ends
*
*
