Exploded diagrams of liquid ends
Liquid end 0232
SS
60_07-104_00_36-04_2
The listed items are included in the spare parts kit.
* Customer accessories
Subject to technical alterations.
Connector kit 12 mm SS 104245
Discharge valve set 12 mm SST 809446
Diaphragm 0232 1000251
Suction valve set 12 mm SST 809447
Connector kit
4 valve balls 404281
12 seals PTFE 483975
Spare parts kits for:
Type Material Order No.
0232 SST 1001736
