ProMinent
®
Page 12
Technical Data
Beta
®
/4 at 180 strokes/minute and 100 % stroke length
4.3 Capacity Data
Beta
®
/ *** - self-degassing types at 180 strokes/minute and 100 % stroke length
* Suction lift when suction line and liquid end are full.
** Priming lift when valves are clean and have been wetted. Intake head at 100 % stroke length and free run-off or vent valve open.
*** The feed rates are minimum feed rates and relat to water.
**** For 6 x 4 mm stainless steel version.
Max. Pump capacity Max. pump capacity Connector Suction Priming
Permissible
Shipping
Pump at maximum at medium size lift* lift**
admission
weight
type back pressure back pressure oØ x iØ
pressure
PP,
NP
bar l/h ml/stroke bar l/h ml/stroke mm m WG m WG bar approx. kg
1601 16 0.59 0.055 8 0.78 0.072 6x4 – 1.8 0.5 2.9
1001 10 0.72 0.067 5 0.84 0.078 6x4 – 1.8 0.5 2.9
0701 7 0.84 0.078 3.5 0.84 0.078 6x4 – 1.8 0.5 2.9
0401 4 0.9 0.083 2 1.02 0.09 6x4 – 1.8 0.5 2.9
1602 16 1.4 0.13 8 1.74 0.16 6x4 – 2.1 0.5 2.9
1002 10 1.7 0.16 5 2.0 0.18 6x4 – 2.1 0.5 2.9
0702 7 1.8 0.17 3.5 2.1 0.19 6x4 – 2.1 0.5 2.9
0402 4 2.1 0.19 2 2.2 0.20 6x4 – 2.1 0.5 2.9
1005 10 3.6 0.33 5 4.0 0.37 8x5 – 2.7 0.5 3.1
0705 7 3.9 0.36 3.5 4.3 0.40 8x5 – 2.7 0.5 3.1
0405 4 4.2 0.39 2 4.4 0.41 8x5 – 2.7 0.5 3.1
0708 7 6.6 0.61 3.5 7.5 0.69 8x5 – 2.0 0.5 3.1
0408 4 7.5 0.69 2 8.1 0.75 8x5 – 2.0 0.5 3.1
0413 4 10.8 1.00 2 12.6 1.17 8x5 – 2.5 0.5 3.1
0220 2 16.2 1.50 1 18.0 1.67 12x9 – 2.0 0.5 3.1
Max. Pump capacity Max. pump capacity Connector Suction Priming
Permissible
Shipping
Pump at maximum at medium size lift* lift**
admission
weight
type back pressure back pressure oØ x iØ
pressure
PP, NP,
PV, TT/SS
bar l/h ml/stroke bar l/h ml/stroke mm m WG m WG bar approx. kg
1000 10 0.74 0.07 5 0.82 0.076 6x4 6 1.8 8 2.9 / 3.6
0700 7 0.8 0.07 3.5 0.9 0.08 6x4 6 1.8 8 2.9 / 3.6
0400 4 0.84 0.08 2 1.1 0.105 6x4 6 1.8 8 2.9 / 3.6
1601 16 1.1 0.10 8 1.4 0.13 6x4 6 2.0 8 2.9 / 3.6
1001 10 1.3 0.12 5 1.5 0.14 6x4 6 2.0 8 2.9 / 3.6
0701 7 1.4 0.13 3.5 1.6 0.15 6x4 6 2.0 8 2.9 / 3.6
0401 4 1.5 0.14 2 2.3 0.21 6x4 6 2.0 8 2.9 / 3.6
1602 16 2.1 0.19 8 2.5 0.24 6x4 6 2.5 5.5 2.9 / 3.6
1002 10 2.4 0.22 5 2.8 0.25 6x4 6 2.5 5.5 2.9 / 3.6
0702 7 2.6 0.24 3.5 3.0 0.28 6x4 6 2.5 5.5 2.9 / 3.6
0402 4 2.8 0.26 2 4.0 0.37 6x4 6 2.5 5.5 2.9 / 3.6
1005 10 4.4 0.41 5 5.0 0.46 8x5**** 5 3.0 3 3.1 / 4.5
0705 7 4.7 0.44 3.5 5.4 0.50 8x5**** 5 3.0 3 3.1 / 4.5
0405 4 5.3 0.49 2 7.1 0.66 8x5**** 6 3.0 3 3.1 / 4.5
0708 7 7.1 0.66 3.5 8.4 0.78 8x5 4 2.0 2 3.1 / 4.5
0408 4 8.3 0.77 2 10.6 0.98 8x5 4 2.0 2 3.1 / 4.5
0413 4 12.3 1.14 2 14.2 1.31 8x5 3 2.5 1.5 3.1 / 4.5
0220 2 19.0 1.76 1 20.9 1.94 12x9 2 2.0 1 3.1 / 4.5
