ProMinent
®
Page 11
Dimensions Beta
®
/ 4 / Beta
®
/ 5
Technical Data
Materials option: TT
K
F
148/160
95/101
E
80/80
92/102
41/36
M
132/144
81/96
10/15
L
M
K
L
10/15
132/144
E
80/80
F
41/36
92/102
95/101
81/96
148/160
Dimensions Beta
®
/ 4 / Beta
®
/ 5
Materials option: SS
Beta
®
/ 4 Beta
®
/ 5
1000 – 1601 1602 1005 0708 – 0413 0220 1605 1008 – 0713 0420 0232
E 34 27 25 -8 -9 31 -2 -3 -10
F 156 164 165 198 199 171 203 204 212
K 78 72 75 77 77 75 77 77 78
L 89 89 88 91 93 88 91 93 93
M 51 (Ø 60) 66 (Ø 70) 68 (Ø 80) 81 (Ø 85) 81 (Ø 85) 68 (Ø 80) 81 (Ø 85) 81 (Ø 85) 96 (Ø 100)
Beta
®
/ 4 Beta
®
/ 5
1000 – 1601 1602 1005 0708 – 0220 1605 1008 – 0420 0232
E 26 19 17 -13 23 -7 -15
F 164 172 173 203 179 209 217
K 78 72 75 77 75 77 78
L 91 91 90 95 90 95 95
M 51 (Ø 60) 66 (Ø 70) 68 (Ø 80) 81 (Ø 85) 68 (Ø 80) 81 (Ø 85) 96 (Ø 100)
