ProMinent delta DLTa optoDrive User Manual

138
14
25
57
191
K
L
Ø 90
7
120
140
E
150
238
F
P_DE_0047_SW
Fig. 34: Dimensional drawing delta
®
type with bleed valve, material version NP - dimensions in mm
2508 / 1608 1612 1020 0730
E 63 60 54 53
F 235 239 245 246
K 110 110 112 112
L 138 138 140 140
7
120
191 129
P_DE_0042_SW_2
25
6x4
138 109
57
25
75
150
Ø 90
228
238
140
Fig. 35: Dimensional drawing delta
®
type 1612 - 0730, material version PV - dimensions in mm
Dimensional drawing delta
®
type with
bleed valve, material version NP
Dimensional drawing delta
®
type 1612 -
0730, material version PV
Dimensional drawings
91
