7
120
191 133
26
138 115
57
25
65
150
Ø 106
238
244
140
P_DE_0043_SW_2
6x4
Fig. 36: Dimensional drawing delta
®
type 0450 - 0280, material version PV - dimensions in mm
7
120
191 128
P_DE_0044_SW_2
138 113
57
25
47
150
Ø 84,5
238
252
140
Fig. 37: Dimensional drawing delta
®
type 1612 - 0730, material version SS - dimensions in mm
Dimensional drawing delta
®
type 0450 -
0280, material version PV
Dimensional drawing delta
®
type 1612 -
0730, material version SS
Dimensional drawings
92
