Item. Description 1612 1020 0730
1 Connector kit 12/9 PCE 817049 817049 817049
Connector kit 8/5 PCE 817048 817048 817048
Connector kit 12/9 PCB 817051 817051 817051
Connector kit 8/5 PCB 817053 817053 817053
3 4 Valve balls 404281 404281 404281
4 Bleed valve 791365 791365 791365
5 Discharge valve compl. PCE 1001439 1001439 1001439
Discharge valve compl. PCB 1001438 1001438 1001438
6 Diaphragm 1000248 1000249 1000250
7 Safety diaphragm 1027414 1027414 1027414
8 Diaphragm rupture reporter* 1027416 1027416 1027416
9 Suction valve compl. PCE 1001435 1001435 1001435
Suction valve compl. PCB 1001434 1001434 1001434
Spring (item 2) and diaphragm rupture reporter (item 8) are accessories. The items listed are included in the spare
parts kit, excluding the diaphragm rupture reporter. Technical changes reserved.
Exploded view drawings
