Fig. 8: Fitting the profile seal on the bottom section of the controller housing
5. Position the profile seal evenly around the upper edge of bottom section of the
DULCOMETER
®
Compact Controller housing. Arrange the clips (1) as shown in
the figure
ð
Ensure that the profile seal evenly surrounds the upper edge of the housing.
6.
Insert the bottom section of the DULCOMETER
®
Compact Controller housing with
the profile seal from behind into the cut-out and use three screws to secure it in
place
Assembly and installation
27
