Fig. 10: Push and lock the ribbon cable in its base
9. Push and lock the ribbon cable (1) in its base
10. Screw the top section of the controller housing onto the bottom section of the
DULCOMETER
®
Compact Controller housing
11. Once again check that the profile seals are fitted properly
ð
IP 54 degree of protection can only be provided if the control panel is mounted
correctly
Assembly and installation
29
