Drill hole
no.
Size
Descrip‐
tion
Ter‐
minal
Ter‐
minal
no.
Pin Function Recom‐
mended
cable Ø
Remark
1 / M20 Sensor XE2 2 red Meas‐
uring
input
Conduc‐
tivity
sensor
with/
without
tempera‐
ture
sensor
5.6 mm ①
XE3 1 black
2 blue
XE4 1 yellow/
green
5 mm
2 brown
①Pass the cable through the M20/2x5 mm multiple seal insert when using an external
temperature sensor
2 / M16 Standard
signal
output
XA1 1 + 15V e.g.
recorder /
actuator
4.5* ②
2 -
Contact
input
XK1 1 + Pause
2 -
Relay
output
XR2 1 f-relay
2
②Pass 1 cable (4-wire) through the M16 / 2x4.5 mm multiple seal insert
3 / M16 Relay
output
XR1 1 COM Raise/
lower sol‐
enoid
valve
5 mm ③
2 NO
Relay
output
XR1 1 COM Limit
value
relay
5 mm
2 NO
