Drill hole
no.
Size
Descrip‐
tion
Ter‐
minal
Ter‐
minal
no.
Pin Function Recom‐
mended
cable Ø
Remark
Relay
output
XR1 1 COM Alarm
relay
5 mm
3 NC
③ Pass cable through M16 single seal insert
4 / M16 Mains
connec‐
tion
XP1 1 N 85 … 253
V effec‐
tive
6.5 mm ④
2 L
④ Pass cable through M16 single seal insert
Assembly and installation
