ProMinent gamma/ X Supplementary Operating Instructions

Reg‐
ister
Description Type Display / purpose
GMXa
50 Modbus module active UINT8 0 - NOT ACTIVE
1 - ACTIVE
X
51 Baud rate UINT8 0 - 9600 Bits/sec
1 - 19200 Bits/sec
2 - 38400 Bits/sec
X
52 Modbus address UINT8 1… 247 X
53 Parity bit UINT8 0 - NONE
1 - ODD
2 - EVEN
X
54 Number of stop bits UINT8 0 - 1 STOP BIT
1 - 2 STOP BITS
X
55 Number of data bits UINT8 0 - 7 BIT
1 - 8 BIT
X
56 Bus connector UINT8 0 - DISABLE
1 - ENABLE
2 - IGNORED
X
57 Software version of the Modbus
module
UINT32 Format: XX.XX.XX.XX (depending on project) X
59 Hardware version of the
Modbus module
UINT32 Format: XX.XX.XX.XX (depending on project) X
61 Cyclic timeout time U16 X
63 Modbus endianness pattern UINT32 Pattern "0xAABBCCDD" is stored in the pump
and can be read out using this register enabling
the endianness of the Modbus access to be deter‐
mined from the master
X
3.9.3 "Production data pump module-specific" register
These register inputs are all only for function code "0x03" (Read
only).
Reg‐
ister
Description Type Display / purpose
GMXa
200 Version structure definition
"Production data" Control
module
UINT16 Format: XXXX, consecutive version number X
201 10-digit serial number Control
module
STRING[1
0]
ASCII coding 10 characters X
206 Identification tester/test equip‐
ment Control module
STRING[4] ASCII coding 4 characters X
208 ICT testing date Control
module
STRING[1
0]
ASCII coding 10 characters
Date format: DD.MM.YYYY
X
Supplementary Operating Instructions for Modbus RTU
49

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
