5.4 Installation
CAUTION!
Degree of protection IP 65
– IP 65 degree of protection only applies if the
appropriate assembly accessories (cable open‐
ings etc.) have been fitted correctly.
The connection to the existing LAN infrastructure is provided by a
suitable LAN cable, e.g. twisted pair cable (CAT5 or higher) to
comply with IP 65 with a screwed M12x1 plug, 4-pin, D-coded to
IEC 61076-2-101. Complies with IEEE 802.3.
Tab. 46: Connectors
Module label Meaning
OUT Port 1
IN Port 2
Mains extension:
n Copper-based twisted pair cable (TP) maximum 100 metres.
5.5 Operation
5.5.1 General
Using the connected PROFINET
®
module, the pump in the PRO‐
FINET
®
represents a device with slave functionality. In this context,
user data is cyclically transmitted.
5.5.2 GSDML File
The GSDML file must be used to configure the master. The
GSDML file describes all the features of the pump in PROFINET
®
mode (keywords, diagnostics, modules, sub-modules). The
GSDML file can be downloaded from the PROFINET
®
website and
from the ProMinent website. The file name is clearly indicated:
GSDML-V2.32-Prominent-GMXa-20170721.xml.
5.5.3 Description of the data objects gamma/ X, GMXa
Tab. 47: Status and control
Module/
slot
Index Name Module
name
Type Dataflow * Description
bit Name Function
1 1 State Status UINT32 L 0 Service There are service
requests
1 Mes‐
sages
There are reports
2 Mode 00 – stop
03 – contact
Bus installation
Supplementary Operating Instructions for PROFINET
®
91
