ProMinent gamma/ X Supplementary Operating Instructions

4
Supplementary Operating Instructions PROFIBUS
®
4.1 Prerequisites............................................................... 65
4.2 Adjusting the pump..................................................... 65
4.2.1 General.................................................................... 65
4.2.2
Activating / deactivating PROFIBUS
®
......................
65
4.2.3 Setting the slave address........................................ 66
4.3
Special features in PROFIBUS
®
mode.......................
67
4.3.1 General.................................................................... 67
4.3.2 Display..................................................................... 67
4.3.3
LEDs on the PROFIBUS
®
module........................... 68
4.3.4 Use metering monitor.............................................. 68
4.4 Installation................................................................... 69
4.5 Operation.................................................................... 70
4.5.1 General.................................................................... 70
4.5.2 GSD file................................................................... 70
4.5.3 Data objects gamma/ X, GMXa............................... 70
4.5.4 Data objects gamma/ L, GALa................................. 79
4.1 Prerequisites
Personnel must be familiar with the contents of the "Operating
Instructions for Solenoid Metering Pump gamma /X, GMXa"!
The pump must have the identity code feature "Control types": "R"
PROFIBUS
®
DP interface M 12". The menu item
‘Fieldbus’ is then
available in the operating menu. (When
‘Fieldbus è active’ is set,
‘Settings è PROFIBUS’ also appears in the operating menu.)
4.2 Adjusting the pump
4.2.1 General
The pump with PROFIBUS
®
functionality is adjusted in the same
way as the standard pump, with the addition of the bus function‐
ality.
In the event of a pause longer than 60 s, the
adjustment process is cancelled.
Using the connected PROFIBUS
®
module, the PROFIBUS
®
pump
represents a device with slave functionality in conformity with DP-
V1. This means that the payload is transferred both cyclically and
acyclically.
4.2.2
Activating / deactivating PROFIBUS
®
In order for the pump to be controlled using the PROFIBUS
®
,
‘Fieldbus’ must be set to ‘Active’ in the operating menu.
1.
To access the
‘Menu’ : press [Menu] .
ð
The cursor immediately points to ‘Information’ .
Supplementary Operating Instructions PROFIBUS
®
65

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
