ProMinent gamma/ X Supplementary Operating Instructions

3.9.7 "Accessories 1" register
These register inputs are all for function code "0x03", "0x06", 0x10
and 0x17 (Read / Write).
Reg‐
ister
Description Type Display / purpose
GMXa
2000 Diaphragm monitoring "oper‐
ating mode"
BOO‐
LEAN
Configuration as to how the pump should react to
a "Diaphragm rupture" event:
0 - WARNING
1 - ERROR
X
3.9.8 "Accessories 2" register
These register inputs are all for function code "0x03", "0x06", 0x10
and 0x17 (Read / Write).
Reg‐
ister
Description Type Display / purpose
GMXa
2100 Activating metering monitor BOO‐
LEAN
Activation/deactivation of the metering monitor
0 - METERING MONITOR DEACTIVATED
1 - METERING MONITOR ACTIVATED
X
2101 "Number of defective strokes
permitted before reporting"
metering monitoring
UINT8 Setting how many defective strokes metering
monitoring should wait before triggering an event.
The event is determined using the "metering mon‐
itoring operating mode" parameter;
the requirement is that the metering monitor has
been activated
0 … 125 strokes
X
2102 Metering monitoring "operating
mode"
BOO‐
LEAN
Configuration as to how the pump should react to
a "metering monitoring" event:
0 - WARNING
1 - ERROR
X
2103 "Level or stroke" metering mon‐
itoring
BOO‐
LEAN
Type of metering monitoring:
0 - LEVEL MONITORING
1 - PULSE WITH STROKE
X
2104 "Fault level" metering moni‐
toring
BOO‐
LEAN
With level monitoring: Which level displays the
fault?
0 - "HIGH" INDICATES FAULT
1 - "LOW" INDICATES FAULT
X
Supplementary Operating Instructions for Modbus RTU
61

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
