Reg‐
ister
Description Type Display / purpose
2105 "Behaviour in auxiliary"
metering monitoring
BOO‐
LEAN
Behaviour with active auxiliary operating mode
0 - MONITORING DEACTIVATED WITH AUXIL‐
IARY
1 - MONITORING ACTIVATED WITH AUXILIARY
X
2106 "Activating system interface"
metering monitoring
BOO‐
LEAN
System interface can be deactivated/activated
Condition for activating the system interface:
metering monitoring previously deactivated by
"activate metering monitoring" parameter
0 - SYSTEM INTERFACE DEACTIVATED
1 - SYSTEM INTERFACE ACTIVATED
X
3.9.9 "Accessories 3" register
These register inputs are all for function code "0x03", "0x06", 0x10
and 0x17 (Read / Write).
Reg‐
ister
Description Type Display / purpose
2200 "Input level warning" level mon‐
itoring
BOO‐
LEAN
Parameter is used with 2-stage level monitoring.
Warning detection performed without inversion via
HIGH level at level warning input
0 - DO NOT INVERT INPUT LEVEL
1 - INVERT INPUT LEVEL
X
2201 "Input level level fault" level
monitoring
BOO‐
LEAN
Parameter is used with 2-stage level monitoring.
Fault detection is performed without inversion via
a HIGH level at the level fault input
0 - DO NOT INVERT INPUT LEVEL
1 - INVERT INPUT LEVEL
X
2202 "Switchover" level monitoring BOO‐
LEAN
This setting can be used to switch between 2-
stage and continuous level monitoring
0 - ACTIVATE 2-STAGE LEVEL MONITORING
1 - ACTIVATE CONTINUOUS LEVEL MONI‐
TORING
X
2203 "Warning threshold cont. mode"
level monitoring
UINT8 With continuous level monitoring:
Specification of a threshold value (in [%] of the
maximum level); if this threshold value is not
reached, a warning is generated by the level mon‐
itoring
0 … 100%
X
Supplementary Operating Instructions for Modbus RTU
62
