ProMinent gamma/ X Supplementary Operating Instructions

Tab. 50: Strokes / quantity and individual data
Module/
slot
Index Name Module
name
Type Dataflow * Description
11 1 Reset
stroke
counter
Strokes/
quantity
UINT8 S If the value changes from 1 to 0,
the
‘Stroke counter’ (total
number of strokes) is reset
2 Reset
quantity
counter
UINT8 If the value changes from 1 to 0,
the
‘Volume counter’ (total
number of litres) is reset
3 Stroke
counter
UINT32 L Count the number of strokes -
since the last reset (
‘Stroke
counter’ )
4 Quantity
counter
FLOAT32 Counts the metering volume in
litres - since the last reset
(
‘Volume counter’ )
5 Litres per
stroke
FLOAT32 Litres per stroke
* R = read, W = write
5.5.4
Diagnostic messages and types of data access
The diagnostic messages are shown in plain text in the PLC.
Error type Diagnostic messages
12755 Limit error when writing
12773 Limit error when reading
13011 Protected value
13029 Protected value
13267 Device not in remote mode
13285 Device not in remote mode
13523 Option not installed
13541 Option not installed
13779 Service not defined
13797 Service not defined
14035 Value cannot be changed
14053 Value cannot be changed
Tab. 51: Data access types
Value Meaning
0xD3 Write access
0xE5 Read access
Supplementary Operating Instructions for PROFINET
®
97

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
