ProMinent gamma/ X Supplementary Operating Instructions


Start up the device in accordance with the following start-up regu‐
lations:
This device complies with Part 15 of the FCC Regulations. The fol‐
lowing 2 conditions must be fulfilled for operation: (1) This device
should not cause any hazardous interference, and (2) this device
should tolerate all interference, including interference that can
cause undesirable operation.
1.3
Prerequisites
Prerequisites for operation:
n Metering pump gamma/ X with Bluetooth functionality (identity
code characteristic "Remote stop/Remote control" = "B, with
Bluetooth")
n The metering pump gamma/ X has been fully electrically and
hydraulically installed
n Bluetooth-enabled Android smart device - see
Ä Tab. 1 ‘These
Android smart devices support the "gamma/ X" app (dated
01.09. 2015):’ on page 6
n Only for handling log files and downloading the app: the smart
device has to have access to the internet.
n The "gamma/ X" app can be downloaded free of charge from
the Google Play Store:
CAUTION!
Only download the "gamma /X" app from the
Google Play Store - not from other sources.
Tab. 1: These Android smart devices support the "gamma/ X" app (dated 01.09. 2015):
Manufacturer Model Android operating system
HTC One M8 5.0.1
Sony Xperia Z3 Compact 5.0.2
Motorola Moto G (2nd generation) 5.0.2
Huawei Ascend P7 4.4.2
LG Nexus 5 5.1.1
Samsung Galaxy S4 4.4.2
Samsung Galaxy Tab 4 4.4.2
Fig. 1: QR code for "gamma/ X" down‐
load app
Supplementary Operating Instructions for Bluetooth Control
6

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
