ProMinent gamma/ X Supplementary Operating Instructions

Order Number Name Explanation
62 Contact memory For "1", the volumes to be deliv‐
ered are added up for each addi‐
tional batch contact; for "0", the
remaining volumes are deleted
and a new contact process is
started (analogous to "batch
memory")
71 Setpoint final concentration Desired final concentration in con‐
centration mode
72 Actual value final concentration current final concentration in con‐
centration mode
81 Dosing monitor Activate/deactivate metering mon‐
itoring:
0 – deactivated
1 – activated / warning
3 – activated / fault
91 Fault - see "data objects GMXa" table
92 Warnings - see "data objects GMXa" table
101 Reset stroke counter Reset stroke counter by changing
"1" to "0"
102 Reset metering quantity counter Reset metering volume counter by
changing "1" to "0"
103 Deletable stroke counter Number of strokes since the last
reset
104 Deletable metering quantity
counter
Totalled metering volumes since
the last reset
105 Litres per stroke Litres per stroke
111 Identity code Pump identity code
112 Serial number Pump serial number
113 Pump name Pump name, freely determinable
114 Installation site Installation site, freely determi‐
nable
4.5.4 Data objects gamma/ L, GALa
So that the pump can participate in the cyclic data
transfer, the initial parameters must be transferred
from the master. To do this only standard para‐
metrisation is necessary; there are no application-
specific parameters.
Supplementary Operating Instructions PROFIBUS
®
79

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
