ProMinent gamma/ X - Control Elements; Installation, Electrical

2.2 Control Elements
P_G_0077_SW
3
2
1
Fig. 3: Control Elements
1 Status LED CAN bus
2 Socket "CAN bus"
3 Device LEDs
2.3 Installation, electrical
CAUTION!
Pump can be damaged
If the CAN cable is not correctly screwed in, the
IP65 protection rating is not achieved.
– Manually screw in the CAN cable glands until
they reach the stop.
