ProMinent gamma/ X Supplementary Operating Instructions

*
**
***
A0203
Ignore the flash codes for approx. 2 minutes after
connecting the metering pump.
For "Error messages about CANopen-telegram",
see the end of the appendix.
2.6 Accessories
Accessories Order no.
T-coupler M12 5-pin CAN 1022155
Termination resistance M12 coupling 1022154
Termination resistance M12 plug 1022592
Connecting cable - CAN, M 12, 5-pole, 1 m 1022139
Connecting cable - CAN, M 12, 5-pole, 2 m 1022140
Connecting cable - CAN, M 12, 5-pole, 5 m 1022141
Connecting cable - CAN, sold by the metre 1022160
Coupling, M12, 5-pole Screw connector 1022157
Plug CAN M12, 5-pole Screw connector 1022156
2.7 Appendix
2.7.1
Object list metering pump gamma/ X, GMXa
2.7.1.1 Communication profile area 0x1000-0x1FFF
Index S Name Type Description
1000h 1 p_ident.d_profile U32 Device type
(10.2.1 in 450)
0001
01C2h
RO M
1001h 1 Error register U8 9.6.3 in 301 RO M
1010h 1 Save all parameters U32 RW O
2 Save comm.. parame‐
ters
3 Save process..
parameters
1011h 1 Load(restoredefault)
parameters
U32 RW O
Supplementary Operating Instructions CANopen
19

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
