ProMinent gamma/ X Supplementary Operating Instructions

5
Supplementary Operating Instructions for PROFINET
®
5.1 Prerequisites............................................................... 87
5.2 Adjusting the pump..................................................... 87
5.2.1 General.................................................................... 87
5.2.2
Activating / deactivating PROFINET
®
......................
87
5.2.3
Configuring PROFINET
®
.........................................
88
5.3
Special Features in Active PROFINET
®
Mode...........
89
5.3.1 General.................................................................... 89
5.3.2 Displays................................................................... 89
5.3.3
LEDs on the PROFINET
®
module........................... 90
5.3.4 Use metering monitor.............................................. 90
5.4 Installation................................................................... 91
5.5 Operation.................................................................... 91
5.5.1 General.................................................................... 91
5.5.2 GSDML File............................................................. 91
5.5.3 Description of the data objects gamma/ X, GMXa... 91
5.5.4 Diagnostic messages and types of data access...... 97
5.5.5 PLC error and behaviour of the pump..................... 98
5.1 Prerequisites
Personnel must be familiar with the contents of the "Operating
Instructions for Solenoid Metering Pump gamma /X, GMXa"!
The pump must have the identity code feature "Control type": "E" -
"PROFINET 10". The menu item ‘Fieldbus’ is then available in the
operating menu. (When
‘Fieldbus è active’ is set, ‘Settings
è PROFINET’ also appears in the operating menu.)
5.2 Adjusting the pump
5.2.1 General
The pump with PROFINET
®
functionality is adjusted in the same
way as the standard pump, with the addition of the bus function‐
ality.
The adjustment process is cancelled in the event
of a pause longer than 60 s.
5.2.2
Activating / deactivating PROFINET
®
In order for the pump to be controlled using the PROFINET
®
,
‘Fieldbus’ must be set to ‘Active’ in the operating menu.
1.
To access the
‘Menu’ : press [Menu] .
ð
The cursor immediately points to ‘Information’ .
2. To switch from
‘Information’ to ‘Fieldbus’ : turn the
[Clickwheel] and press.
3. To switch the
‘Fieldbus’ to ‘Inactive / active’ : turn the
[Clickwheel] and press.
Supplementary Operating Instructions for PROFINET
®
87

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
