ProMinent gamma/ X Supplementary Operating Instructions

Module/
slot
Index Name Module
name
Type Dataflow
*
Description
23 -
24 -
25 -
26 -
27 -
28 -
29 -
30 -
31 -
2 Warn‐
ings
UINT16 Bit Name Function
0 Minimum Metering liquid is
low
1 Calibra‐
tion
-
2 Metering
monitor
Metering monitor
warning
3 Dia‐
phragm
rupture
Faulty diaphragm
in the dosing
head
4 Airlock Air in the dosing
head
5 -
6 Cavitation
7 Overpres‐
sure
Overpressure in
the hydraulics
8 Low pres‐
sure
Pressure too low
in the hydraulics
9 -
10 -
11 -
12 -
13 -
14 -
15 -
* R = read, W = write
Supplementary Operating Instructions for PROFINET
®
96

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
