ProMinent gamma/ X Supplementary Operating Instructions

Tab. 49: Error / Warning
Module/
slot
Index Name Module
name
Type Dataflow
*
Description
10 1 Error Error /
Warning
UINT32 L Bit Name Function
0 Minimum Metering medium
level is too low
1 Batch Too many
metering strokes:
> 100 000
2 Analogue
< 4mA
Analogue current
is less than 4 mA
3 Analogue
> 23mA
Analogue current
is greater than 23
mA
4 Metering
monitor
Fault metering
monitoring
5 Dia‐
phragm
rupture
Dosing head dia‐
phragm broken
6 Airlock Air in the dosing
head
7 Overpres‐
sure
Overpressure
(feed chemical)
8 -
9 Cavitation
10 Low pres‐
sure
Pressure too low
(feed chemical)
11 Change
stroke
length
The stroke length
has been
adjusted in locked
state
12 Bleeding Automatic
bleeding is not
possible
13 Bus error Bus error reported
by the module
14 System
error
System compo‐
nent faulty - see
display
15 Module
error
Fault in module
handling
16 -
17 -
18 -
19 -
20 -
21 -
22 -
Supplementary Operating Instructions for PROFINET
®
95

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
