ProMinent gamma/ X Supplementary Operating Instructions

Module/
slot
Index Name Module
name
Type Dataflow * Description
bit Name Function
3 01 – manual
04 – analogue
4 02 – batch
5 Error There are errors -
see "Errors"
6 Warn‐
ings
There are warnings
- see "Warnings"
7 Hand
stop
Pump has been
stopped manually
8 Stop Pump has stopped
9 Priming
key
Pump is in priming
mode (higher-level
function)
10 Auxiliary Pump is in auxiliary
mode (higher-level
function)
11 Pause Pump has been
switched to
‘Pause’ status
(higher-level func‐
tion)
12 Module Fieldbus active
13 Flow Metering monitor is
activated
14 Batch-
Mem.
Batch memory is
activated
15 Cali‐
brated
Pump is calibrated
16 - -
17 - -
18 - -
19 Dia‐
phragm
rupture
Diaphragm rupture
indicator is installed
20 Concen‐
tration
Concentration cal‐
culation is activated
21 - -
22 Cavita‐
tion
Priming occurred
during cavitation
23 Airlock Air in the dosing
head
24 Over‐
pressure
Excessive back
pressure
25 Under‐
pressure
Low back pressure
Supplementary Operating Instructions for PROFINET
®
92

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
