ProMinent gamma/ X Supplementary Operating Instructions

Module/
slot
Index Name Module
name
Type Dataflow * Description
bit Name Function
26 Bleeding Pump vented
27 - -
28 - -
29 - -
30 - -
31 - -
2 1 Start /
Stop
Control UINT8 S Corresponds to
[Start/Stop] key; if Start /
Stop = 0, then the pump is stopped
2 Reset UINT8 If the Reset value is switched from 1 to
0, the internal pump memory is erased
(e.g. with batch metering) and - as far as
possible - existing errors are deleted
* R = read, W = write
Tab. 48: Mode, Flow rate, Max. flow rate, Batch, Contact, Concentration, Metering monitor
Module/
slot
Index Name Module
name
Type Dataflow
*
Description
3 1 Mode Mode UINT8 R, W Value Name Description
0.16 Stop Pump is ready but
not metering.
1 Manual Pump is metering
continuously with
the set volume
2 Batch When triggered, the
pump is metering
the volume set in
the batch code
3 Contact Pump meters
volume in the pre‐
defined time
4 Ana‐
logue
oper‐
ating
mode
Pump is metering in
accordance with the
analogue signal
and the analogue
mode set at the
pump.
17 Manual
(con‐
centr.)
Manual in concen‐
tration mode
18 Batch
(con‐
centr.)
Batch in concentra‐
tion mode
19 Contact
(con‐
centr.)
Contact in concen‐
tration mode
Supplementary Operating Instructions for PROFINET
®
93

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
