3
IntroductionPegasus R4i Product Manual
Storage Disks
The Pegasus R4i is shipped with 3.5 inch 7200 rpm SATA Hard Disk Drive (HDD)
Modules mounted in the drive bays.
Capacity
Total capacity depends on the size of the HDD shipped with the unit.
The Pegasus R4i is shipped with four HDD
RAID function
RAID level support: RAID 0, 1, 1E, 5, 6, 10
OS Support
macOS 10.14+ or newer
Hardware
monitoring
Temperature, Enclosure, Physical drives, Logical drives, RAID controller
Temperature
Operating: 5° ~ 35° C
Non-operating: -40° ~ 70° C
Humidity
Operating: 10% ~ 95% non-condensing
Storage: 5% - 95% non-condensing
Dimensions
337 x 164 x 80 mm (13.3 x 6.5 x 3.2 inch)
Weight
As shipped with all 3.5” HDD installed: 4.2 kg / 9.2 lb (with 4 HDDs)
Certication
FCC, CE, C-Tick, VCCI, BSMI
SpecificationS
